Beaver Hot Dipped Galvanised Screw Pin Dee Shackles (Pail) 0.75t
241308Pper Pail
$112.62 inc GSTTrade $101.36, save $11.26Trade accounts save 10%. Apply with your ABN
| WLL | 0.75t |
| Size | 8mm x 10mm |
| Diameter | 8mm |
| Bucket Weight | 3.85kg |
| QTY per Bucket | 50 |
| Shackle Colour | Hot Dipped Galvanised |
| Bucket Capacity | 2L |
| Inside Width (W) | 13mm |
| Pin Diameter (D) | 10mm |
| Diameter Boss (e) | 21mm |
| Inside Length (L) | 26mm |
| Working Load Limit | 0.75t |
About this product
The Beaver Hot Dipped Galvanised Screw Pin Dee Shackle in 0.75t is the smallest end of the range, built for light lifting, towing and 4WD recovery work where you still want a Grade S rating. The body measures 8mm x 10mm with a 10mm pin diameter, a 13mm inside width and a 26mm inside length, so it takes thinner slings and chain without slop.
Hot dipped galvanising on the body and a yellow painted pin help it stand up to weather on mine sites and construction jobs. The 21mm diameter boss gives the screw pin a solid seat, and the Dee shape keeps side loading out of the equation when you are pulling in line. Grade S gives a high strength to size ratio, and the shackle complies to AS 2741. Check the pin seats fully by hand before every lift.
Common questions
- what is the WLL of a 0.75t beaver dee shackle
- It has a working load limit of 0.75t. That figure applies to in line loading, so keep the pull straight through the bow and pin.
- beaver 8mm dee shackle dimensions
- The body is 8mm with a 10mm pin diameter, 13mm inside width, 26mm inside length and a 21mm diameter boss.
- are galvanised screw pin dee shackles ok for outdoor use
- Yes. This one is hot dipped galvanised with a yellow painted pin, which suits exposed mining and construction work.
Full specifications
| Product Code | Size | WLL | Shackle Colour | Bucket Capacity | QTY per Bucket | Bucket Weight |
|---|---|---|---|---|---|---|
| 241306P | 6mm x 8mm | 0.5t | Hot Dipped Galvanised | 2L | 100 | 2.8kg |
| 241308P | 8mm x 10mm | 0.75t | Hot Dipped Galvanised | 2L | 50 | 3.85kg |
| 241310P | 10mm x 11mm | 1t | Hot Dipped Galvanised | 2L | 30 | 3.9kg |
| 241311P | 11mm x 13mm | 1.5t | Hot Dipped Galvanised | 2L | 20 | 4kg |
| 241313P | 13mm x 16mm | 2t | Hot Dipped Galvanised | 2L | 14 | 4.2kg |
| 241316P | 16mm x 19mm | 3.2t | Hot Dipped Galvanised | 5L | 20 | 11.6kg |
| 241319P | 19mm x 22mm | 4.7t | Hot Dipped Galvanised | 5L | 10 | 10.2kg |
| 241322P | 22mm x 25mm | 6.5t | Hot Dipped Galvanised | 5L | 8 | 11.44kg |
| 241325P | 25mm x 29mm | 8.5t | Hot Dipped Galvanised | 5L | 4 | 8.62kg |
| Product Code | Size | Diameter | Pin Diameter (D) | Inside Width (W) | Inside Length (L) | Diameter Boss (e) |
|---|---|---|---|---|---|---|
| 241306P | 6mm x 8mm | 6mm | 8mm | 12mm | 22mm | 17mm |
| 241308P | 8mm x 10mm | 8mm | 10mm | 13mm | 26mm | 21mm |
| 241310P | 10mm x 11mm | 10mm | 11mm | 17mm | 32mm | 25mm |
| 241311P | 11mm x 13mm | 11mm | 13mm | 18mm | 37mm | 27mm |
| 241313P | 13mm x 16mm | 13mm | 16mm | 21mm | 41mm | 33mm |
| 241316P | 16mm x 19mm | 16mm | 19mm | 27mm | 51mm | 40mm |
| 241319P | 19mm x 22mm | 19mm | 22mm | 32mm | 60mm | 48mm |
| 241322P | 22mm x 25mm | 22mm | 25mm | 37mm | 71mm | 54mm |
| 241325P | 25mm x 29mm | 25mm | 29mm | 43mm | 81mm | 60mm |
