Beaver Hot Dipped Galvanised Commercial Dee Shackles (Pail) 16mm
200316Pper Each
$4.78 inc GSTTrade $4.30, save $0.48Trade accounts save 10%. Apply with your ABN
| D | 18mm |
| F | 30mm |
| L | 60mm |
| W | 33mm |
| d | 15.5mm |
| Size | 16mm |
| Shape | Dee |
| Finish | Galvanised |
| Bucket Weight | 9.18kg |
| Closing Method | Screw |
| QTY per Bucket | 20 |
| Bucket Capacity | 4L |
| Shackle Diameter | 16mm |
About this product
The Beaver Hot Dipped Galvanised Commercial Dee Shackle in 16mm is a general anchoring and connecting shackle, not a lifting fitting. It is the heavier end of the commercial dee range, with a 15.5mm screw pin, 18mm body, 60mm inside length and 33mm width, so it takes chunkier rope, chain and fixed eyes that smaller sizes will not clear. Jaw opening is 30mm.
Made from mild steel with a hot dipped galvanised finish, it stands up better to weather and damp than a plain finish, which suits it to gates, fencing, tie-down points and yard work. The screw pin makes it quick to open and close by hand. Keep it away from any lifting or load bearing job, and note commercial dimensions can vary by plus or minus 10 percent.
Common questions
- can you use beaver commercial dee shackles for lifting
- No. These commercial shackles must not be used for any lifting or load bearing applications, only for general anchoring or connecting.
- what pin size is a 16mm commercial dee shackle
- The 16mm size runs a 15.5mm screw pin, with an 18mm body diameter and a 30mm jaw opening.
- is a galvanised commercial shackle ok outdoors
- The hot dipped galvanised finish on mild steel gives better corrosion resistance, so it handles outdoor anchoring and connecting work well.
Full specifications
| Product Code | Size | Finish | Shape | Closing Method | QTY per Bucket | Bucket Capacity | Bucket Weight |
|---|---|---|---|---|---|---|---|
| 200305P | 5mm | Galvanised | Dee | Screw | 50 | 0.75L | 0.68kg |
| 200306P | 6mm | Galvanised | Dee | Screw | 50 | 0.75L | 1.24kg |
| 200308P | 8mm | Galvanised | Dee | Screw | 40 | 1L | 2.2kg |
| 200310P | 10mm | Galvanised | Dee | Screw | 30 | 2L | 3.36kg |
| 200313P | 13mm | Galvanised | Dee | Screw | 30 | 4L | 7kg |
| 200316P | 16mm | Galvanised | Dee | Screw | 20 | 4L | 9.18kg |
| 200320P | 20mm | Galvanised | Dee | Screw | 6 | 2L | 5.8kg |
| 200323P | 23mm | Galvanised | Dee | Screw | 6 | 4L | 5.8kg |
| 200325P | 25mm | Galvanised | Dee | Screw | 6 | 4L | 10.2kg |
| Product Code | Size | W | L | D | d | F |
|---|---|---|---|---|---|---|
| 200305P | 5mm | 11mm | 19mm | 7mm | 4.5mm | 10mm |
| 200306P | 6mm | 13mm | 26mm | 7mm | 5.5mm | 11mm |
| 200308P | 8mm | 18mm | 32mm | 9mm | 7.8mm | 16mm |
| 200310P | 10mm | 19mm | 38mm | 11mm | 9.8mm | 19mm |
| 200313P | 13mm | 29mm | 55mm | 15mm | 13mm | 26mm |
| 200316P | 16mm | 33mm | 60mm | 18mm | 15.5mm | 30mm |
| 200320P | 20mm | 39mm | 75mm | 22mm | 19mm | 33mm |
| 200323P | 23mm | 45mm | 80mm | 25mm | 22mm | 38mm |
| 200325P | 25mm | 45mm | 80mm | 25mm | 22mm | 38mm |
