Beaver Electro Galvanised Commercial Dee Shackles (Pail) 13mm
200213Pper Each
$3.23 inc GSTTrade $2.91, save $0.32Trade accounts save 10%. Apply with your ABN
| Size | 13mm |
| Shape | Dee |
| Finish | Electro Galvanised |
| Bucket Weight | 6.88kg |
| Closing Method | Screw |
| QTY per Bucket | 30 |
| Bucket Capacity | 4L |
| Shackle Diameter | 13mm |
About this product
The Beaver Electro Galvanised Commercial Dee Shackle in 13mm is a mild steel screw pin shackle for general anchoring and connecting jobs around the yard, the ute or the site. The dee shape keeps the connection in line and holds the pin under straight pull, so it suits tie-downs, gates, fencing and light securing work where you just need two things joined quickly.
At 13mm diameter it sits in the middle of the range, big enough to take a solid chain or rope eye without being awkward in the hand. The electro galvanised finish gives reasonable protection against surface rust in general use. Important point: these are commercial shackles and must not be used for lifting or any load bearing application. Commercial specs can vary up to plus or minus 10 percent on actual dimensions.
Common questions
- can you use a commercial dee shackle for lifting
- No. These are commercial shackles for general anchoring and connecting only, and must not be used for lifting or any load bearing application.
- what is a 13mm beaver commercial dee shackle made of
- Mild steel with an electro galvanised finish for general corrosion protection.
- what is the difference between a dee shackle and a bow shackle
- A dee shackle has a narrower body suited to straight in-line pull, while a bow shape allows more room for multiple connections. This one is a dee with a screw pin closing method.
Full specifications
| Product Code | Size | Finish | Shape | Closing Method | QTY per Bucket | Bucket Capacity | Bucket Weight |
|---|---|---|---|---|---|---|---|
| 200205P | 5mm | Electro Galvanised | Dee | Screw | 50 | 0.75L | 0.7kg |
| 200206P | 6mm | Electro Galvanised | Dee | Screw | 50 | 0.75L | 1.24kg |
| 200208P | 8mm | Electro Galvanised | Dee | Screw | 40 | 1L | 2.2kg |
| 200210P | 10mm | Electro Galvanised | Dee | Screw | 30 | 2L | 3.24kg |
| 200213P | 13mm | Electro Galvanised | Dee | Screw | 30 | 4L | 6.88kg |
| 200216P | 16mm | Electro Galvanised | Dee | Screw | 20 | 4L | 8.89kg |
| 200220P | 20mm | Electro Galvanised | Dee | Screw | 6 | 2L | 4.88kg |
| 200225P | 25mm | Electro Galvanised | Dee | Screw | 6 | 4L | 9.86kg |
| Size | W | L | D | d | F |
|---|---|---|---|---|---|
| 5mm | 11mm | 19mm | 7mm | 4.5mm | 10mm |
| 6mm | 13mm | 26mm | 7mm | 5.5mm | 11mm |
| 8mm | 18mm | 32mm | 9mm | 7.8mm | 16mm |
| 10mm | 19mm | 38mm | 11mm | 9.8mm | 19mm |
| 13mm | 29mm | 55mm | 15mm | 13mm | 26mm |
| 16mm | 33mm | 60mm | 18mm | 15.5mm | 30mm |
| 20mm | 39mm | 75mm | 22mm | 19mm | 33mm |
| 25mm | 50mm | 90mm | 27mm | 24mm | 45mm |
