Beaver Proof Coil Chain General Link (25kg Pail) 3mm
100103Pper Each
$184.45 inc GSTTrade $166.01, save $18.44Trade accounts save 10%. Apply with your ABN
| F | 13.1mm |
| R | 16.6mm |
| S | 3mm |
| Finish | Self Colour |
| m/25kg | 175m/25kg |
| Nominal Size | 3mm |
About this product
The Beaver Proof Coil Chain General Link in 3mm is a light general purpose chain for restraint, fencing, gate work and other non-lifting jobs around the yard or site. It is the finest size in the range, with a 3mm wire diameter, 13.1mm link length and 16.6mm outside width, so it runs through small gaps and hardware that heavier chain will not fit.
Made from low carbon steel with a self colour finish, this is a non-rated chain. It carries no working load limit and is not suitable for lifting. The proof coil description refers to the consistent link count through any given length, which keeps the chain running evenly over a sprocket or through a guide. If the job involves suspending or lifting a load, step up to a properly rated grade lifting chain instead.
Common questions
- can you lift with 3mm proof coil chain
- No. Beaver proof coil chain is non-rated and is not suitable for lifting purposes, so use a rated lifting chain for any load that leaves the ground.
- what is proof coil chain made of
- It is manufactured from low carbon steel and supplied in a self colour finish.
- what size is 3mm proof coil chain link
- The 3mm size has a 3mm wire diameter, a link length of 13.1mm and an outside link width of 16.6mm.
Full specifications
| Product code | Nominal Size | S | R | F | Finish | m/25kg |
|---|---|---|---|---|---|---|
| 100103P | 3mm | 3mm | 16.6mm | 13.1mm | Self Colour | 175m/25kg |
| 100104P | 4mm | 3.9mm | 20mm | 15.6mm | Self Colour | 87m/25kg |
| 100105P | 5mm | 4.7mm | 25mm | 18mm | Self Colour | 61m/25kg |
| 100106P | 6mm | 6mm | 27mm | 24mm | Self Colour | 35m/25kg |
| 100108P | 8mm | 7.6mm | 35.8mm | 29.2mm | Self Colour | 22m/25kg |
Questions about this equipment? Send us a message and we’ll check it against the job.
